Water Inlet valve hole is located on the base of cistern tank on the right hand side
Bottom inlet valve (SP5A). Back inlet valve available as optional item (SP511).
SP511 : Back entry kit for C1/C3/C24, including back entry inlet valve with flexible hose and plug
Dual flush cistern fittings with ceramic lever on the right.
Press lever down for 6 litre flush and up for 3 litre flush.
P trap standard height pan - height from floor to pan rim is 40cm.
Regal Height pan ( floor to pan rim height 48cm ) available : P12
Ceramic soil connection pipes : straight connector to the wall : C29. The S trap connector bending down to the floor : C26
Metal connection bracket.
Close coupled wc must be used with standard Burlington toilet seats
Supplied with floor fixings.
Recommended to be used with cistern tank isolation valve W25
| Product Type | Traditional |
| Overall height | 78cm |
| Material | P5: Pan - Vitreous china C1: Cistern - Ceramic & brass C2: Cistern - Vitreous china C3: Cistern - Vitreous china C4: Cistern - Vitreous china |
| Size | P5: 642 x 355 x 453mm C1: 520 x 327 x 205mm C2: 515 x 205 x 327mm C3: 454 x 327 x 218mm C4: 454 x 327 x 218mm |
| Nett Weight | P5: Pan - 19.25kg C1: Cistern - 16kg C2: Cistern - 16kg C3: Cistern - 14.05kg C4: Cistern - 14.05kg |
| Gross Weight Including Packaging | P5: Pan - 21.65kg C1: Cistern - 18.25kg C2: Cistern - 18.25kg C3: Cistern - 16.25kg C4: Cistern - 16.25kg |
| Packed Dimension | P5: 378 x 680 x 485 = 0.1247 m3 C1: 225 x 540 x 370 = 0.045 m3 C2: 225 x 540 x 370 = 0.045 m3 C3: 235 x 475 x 365 = 0.0407 m3 C4: 235 x 475 x 365 = 0.0407 m3 |
| Colour | P5: Pan - White C3: Cistern - White C4: Cistern - White |
| Barcode | P5: 5055806005228 C4: 5055806002333 |
| Packed Dimension | P5: 378 x 680 x 485 = 0.1247 m3 C1: 225 x 540 x 370 = 0.045 m3 C2: 225 x 540 x 370 = 0.045 m3 C3: 235 x 475 x 365 = 0.0407 m3 C4: 235 x 475 x 365 = 0.0407 m3 |
| Colour | P5: Pan - White C3: Cistern - White C4: Cistern - White |
