Description
Characteristics
- Quality-monitored in accordance with EN 274-3
- With overflow
- Double-sided seals on drain and overflow
- Overflow head with extendible mount can be fastened
Technical data
- Discharge rate : 0.8 l/s
- Overflow discharge rate : 0.6 l/s
- Depth of water seal : 50 mm
Scope of delivery
- Waste outlet
- Trap
- Straight connector made of PE-HD, ø 43 mm
- Ready-to-fit set
- Protection box
- Fastening material
Application purposes
- For bathtubs made of steel, plastic or cast iron
- For standard-size bathtubs
- For bathtubs with valve hole ø 52 mm
Spare Parts
Art. No. | Description |
240.465.00.1 | Waste outlet set for Geberit bathtub drain |
854.454.00.1 | Geberit connection bend with union nut made of PE: d=40-50mm |
241.995.00.1 | Geberit compression joint |
240.569.00.1 | Geberit straight connector with ball joint |
241.675.00.1 | Geberit straight connector with union nut |
240.464.06.1 | Extension to overflow pipe, for Geberit bathtub drain: Rg=40 x 1/8", granite grey |
240.463.06.1 | Geberit overflow bend: granite grey |
854.406.06.1 | Geberit union nut: granite grey |
894.050.16.1 | Geberit compression ring: black |
891.210.00.1 | Geberit compression seal |
150.245.06.1 | Geberit overflow pipe with supplementary connection and sleeve: granite grey |
252.888.06.1 | Geberit union with blind plug: granite grey |
854.713.00.1 | Geberit flat gasket |
240.462.00.1 | Geberit sleeve |
240.461.00.1 | Geberit bellows for overflow head |
240.459.00.1 | Geberit fastening set for overflow head |
241.712.16.1 | Section seal for Geberit bathtub drain with push actuation Push Control: black |
240.458.00.1 | Catch for turn handle actuation, for Geberit bathtub drain with overflow |
Product Details
Art. no. | Surface / Colour |
150.535.21.1 | Gloss chrome-plated |
Downloads
