Description
Characteristics
- Self-supporting frame, powder-coated
- Galvanized feet
- Feet adjustable 0-20 cm
- Concealed cistern with front actuation
- Concealed cistern fully insulated against condensation
- Cistern fulfils standard requirements in accordance with EN 14055, Class II
- Immediate post flush possible with factory setting
- Water supply connection on the left
- Protection cover box for service opening protects against moisture and dirt
- Protection box for service opening can be cut to length without tools
- Equipped with conduit pipe for feed pipe for connection of Geberit AquaClean shower toilets
- With fastening option for electrical connection
Technical data
- Flow pressure : 0.1-10 bar
- Maximum operating temperature, water : 25 °C
- Flush volume, factory setting : 5.8 and 3 l
- Flush volume small, adjustment range : 3-4 l
Scope of delivery
- Water supply connection Rp 1/2" - R?1/2", compatible with MeplaFix, with integrated angle stop valve and hand wheel
- Protection box for service opening
- 2?wall anchors
- 2 protection plugs
- Connection set for WC, ø?90 mm
- Connection bend 90° made of PE-HD, ø 90 / 110 mm
- Adaptor socket made of PE-HD, ø 90 / 110 mm
- 2 threaded rods M12
- Fastening material
Application purposes
- For drywall construction
- For installation in part-height prewall installations
- For wall-hung WCs with connection dimensions in accordance with EN 33:2011
- For wall-hung WCs with projection up to 62 cm
- For floor constructions 0-20 cm
Spare Parts
Art. No. | Description |
Geberit Kappa concealed cistern 15 cm (UP120, Artline) | |
111.892.00.1 | Geberit Duofix hexagon head setscrew with crosshead, self-cutting |
240.189.00.1 | Geberit set of threaded rods M12 (2 pc.) |
362.796.92.1 | Geberit protection plug: d=44.6mm |
362.771.00.1 | Lip seal for Geberit flush pipe: d=45mm |
152.426.11.1 | Geberit connection set for wall-hung WC, length 18.5 cm: d=90mm, d1=45mm, white alpine |
152.426.46.1 | Geberit connection set for wall-hung WC, length 18.5 cm: d=90mm, d1=45mm, matt chrome-plated |
Geberit connector sets for floor-standing WC and wall-hung WC | |
366.820.92.1 | Geberit protective cap: d=90mm |
366.061.16.1 | Geberit connection bend 90° for wall-hung WC: d=90mm, d1=90mm |
367.928.16.1 | Geberit HDPE adaptor socket: d1=90mm, d2=110mm |
387.282.00.1 | Geberit HDPE sleeve: d=90mm |
240.401.00.1 | Geberit pipe bracket for WC outlet bend |
242.886.00.1 | Geberit conduit pipe with branch |
