by Geberit
Save £221.68
Original price
£1,859.68
Current price
£1,638.00
CODE: 131.033.SI.5
Description
Characteristics
- Dual flush
- Compensation of dimensional tolerances possible
- Front cladding made of glass (ESG)
- Cistern fully insulated against condensation
- Side cladding made of aluminium brushed
- Self-supporting
- Adjustable flush volume
- Water supply connection on the rear centre
- Water supply connection on the left/right possible with accessories
- Water supply connection on the bottom
Technical data
- Flow pressure : 0.1-10 bar
- Maximum operating temperature, water : 25 °C
- Flush volume, factory setting : 6 and 3 l
- Flush volume large, adjustment range : 4.5 / 6 l
- Flush volume small : 3 l
- Calculated flow rate : 0.11 l/s
- Minimum flow pressure for calculated flow rate : 0.5 bar
Scope of delivery
- Water supply connection set with 2 angle stop valves, 1/2"
- Flush bend extension 160 mm
- Connection bend made of PP, ø 90 mm
- Sleeve made of EPDM,?ø?44 / 55 mm
- Adaptor socket made of PE-HD, ø 90 / 110 mm
- Fastening material
- Base cover
- Fastening material for drywall
Application purposes
- For floor inlets
- For renovations, conversions and new buildings
- For wall inlets with an inlet height of 18 cm
- For replacing floor-standing WCs with concealed cistern with maximum service opening
- For replacing low-level exposed cisterns
- For replacing half-high level exposed cisterns
- For replacing floor-standing WCs with close-coupled exposed cistern
- For connecting Geberit AquaClean Sela floor-standing WC
- For connecting Geberit AquaClean WC enhancement solutions, with accessories
- For replacing pressure flushing valves
- For mounting on finished floors
- For installation in front of drywalls or solid walls
Spare Parts
Art. No. | Description |
243.440.TA.1 | Cistern lid for Geberit Monolith sanitary module for WC: aluminium brushed |
243.446.00.1 | Technical cistern for Geberit Monolith sanitary module for WC |
240.344.00.1 | Damming device for Geberit exposed cistern AP140 and Geberit Monolith |
243.442.00.1 | Flush bend for Geberit Monolith sanitary modules for WCs |
362.771.00.1 | Lip seal for Geberit flush pipe: d=45mm |
152.434.06.1 | Geberit flush bend extension with sleeve: d=45mm |
243.994.00.1 | Set of consoles for Geberit Monolith sanitary modules for WCs and bidets |
131.112.TA.1 | Set of fixing bolts made of aluminium, for Geberit Monolith side cladding (2 pc.): aluminium brushed |
243.042.JF.1 | Set of fixing bolts made of plastic, for Geberit Monolith side cladding (2 pc.): mid-grey pearl mica |
243.539.00.1 | Side cladding set for Geberit Monolith sanitary module for WC, 114 cm |
243.447.JF.1 | Side part extension for Geberit Monolith sanitary module for WC and bidet: mid-grey pearl mica |
243.444.JF.1 | Cover, bottom, for Geberit Monolith sanitary module for floor-standing WC: mid-grey pearl mica |
242.480.00.1 | Fastening set for Geberit Monolith front cladding |
242.389.00.1 | Flush valve for Geberit Monolith sanitary module for WC |
816.418.00.1 | Flat gasket for Geberit flush valves of exposed and concealed cisterns |
243.293.00.1 | Basket for flush valve, for Geberit Monolith |
242.985.00.1 | Geberit fill valve type 380, lateral water supply connection, 3/8", nipple made of brass |
242.983.00.1 | Geberit fill valve type 380, lateral water supply connection, 3/8", nipple made of brass |
242.984.00.1 | Geberit fill valve type 380, lateral water supply connection, 3/8", nipple made of brass |
Geberit fill valve type 380, side connection | |
242.670.00.1 | Extension for flush valve, for Geberit Monolith sanitary module for WC, 114 cm |
242.387.00.1 | Actuation lever with console bracket, for Geberit Monolith sanitary module for WC |
242.662.SI.1 | Front cladding for Geberit Monolith sanitary module for wall-hung WC, 114 cm: glass / white |
242.662.SJ.1 | Front cladding for Geberit Monolith sanitary module for wall-hung WC, 114 cm: glass / black |
242.662.SQ.1 | Front cladding for Geberit Monolith sanitary module for wall-hung WC, 114 cm: glass / umber |
242.662.TG.1 | Front cladding for Geberit Monolith sanitary module for wall-hung WC, 114 cm: glass / sand |
242.667.SI.1 | Front cladding for Geberit Monolith sanitary module for floor-standing WC, 114 cm: glass / white |
242.667.SJ.1 | Front cladding for Geberit Monolith sanitary module for floor-standing WC, 114 cm: glass / black |
242.667.SQ.1 | Front cladding for Geberit Monolith sanitary module for floor-standing WC, 114 cm: glass / umber |
242.667.TG.1 | Front cladding for Geberit Monolith sanitary module for floor-standing WC, 114 cm: glass / sand |
131.083.16.1 | Geberit straight connector set for WC |
131.088.29.1 | Geberit Monolith S-bend set for wall-hung WC |
Geberit Monolith connection set for floor-standing WC, with S-bend in ABS | |
131.082.16.1 | Geberit connection set for floor-standing WC |
Geberit Monolith connection set for floor-standing WC, with connection bend 90° | |
131.081.11.1 | Geberit P-bend set for floor-standing WC |
Geberit Monolith connection set for floor-standing WC, with P-bend | |
131.084.16.1 | Geberit straight connector set for wall-hung WC |
Geberit Monolith connection set for floor-standing WC, with straight connector | |
131.108.11.1 | Geberit straight connector set for wall-hung WC, stepped by 7 cm |
131.085.11.1 | Geberit straight connector set for wall-hung WC, stepped by 3 cm |
Geberit connector sets for floor-standing WC and wall-hung WC | |
388.352.29.1 | Geberit connection set for wall-hung WC, with straight connector stepped by 5 cm |
131.138.00.1 | Bottom water supply connection set for Geberit Monolith sanitary module for WC, 114 cm |
131.071.21.1 | Lateral water supply connection set for Geberit Monolith sanitary module for WC: gloss chrome-plated |
241.487.00.1 | Geberit O-ring |
Product Details
Art. no. | Surface / Colour |
131.033.SQ.5 | Glass / umber |
131.033.SI.5 | Glass / white |
131.033.TG.5 | Glass / sand |
131.033.SJ.5 | Glass / black |
Downloads
