Burlington 3 Tap Hole Mixer with Traditional Pop Up Waste

by Burlington
Sold out
£249.16

Free UK Delivery

Estimated delivery 2-5 working days

90 Days Returns

30 days refund & 90 days exchange

100% Secure Checkout

Bank-grade PCI Level 1 security

Illustrated Code

AN12
  • T14: Three tap hole tap, with pop up (excluding tap heads & base)
  • T2: Anglesey tap handles (pair)
  • TOTAL: Code: AN12

Additional Information

Supplied with flow straighter - this is for use with low water pressure

Supplied with neoperl aerator - this is for use with high water pressure

Supplied with pop up waste. If flip top waste or plug & chain is required then these can be purchase seperately.

Guarantee

10 years domestic installations
1 year commercial installations

Standards Information

BS 5412:1996 Specification for low-resistance single taps and combination tap assemblies (nominal size 1 and 3) suitable for operation at PN 10 max. and a minimum flow pressure of 0.01 MPa (0.1 bar)
BS EN 200:2008 Sanitary tapware. Single taps and combination taps for water supply systems of type 1 and type 2. General technical specification

Available Spare Parts

  • SP450: Aerator for product T5, T5-QT, T6, T6-QT, T7, T7-QT, T12, T12-QT, T13, T13-QT, T14, T14-QT, T15, T15-QT, T26, T26-QT, CH19, CH20, CH21, CH22, CH23
  • SP523: Bell shape part for T5, T6, T7, T8, T9, T10, T11, T12, T13, T14, T15, T16, T26, T24, T25 and relative Quarter turn taps
  • SP931 decorative cap of Burlington tap handles: Cold
  • SP930 decorative cap of Burlington tap handles: Hot
  • SP468: Decorative cover for T14
  • SP93: Fixing screw and washer for valve handle (T1, T2, T3, V1, V2, V3)
  • SP449: Flow straightener for product T5, T5-QT, T6, T6-QT, T7, T7-QT, T12, T12-QT, T13, T13-QT, T14, T14-QT, T15, T15-QT, T16, T16-QT, T26, T26-QT, CH19, CH20, CH21, CH22, CH23
  • SP451: Key for T5, T5-QT, T13-QT, T13, T12-QT, T12, T16-QT, T16, T14, T14-QT
  • SP634: Pair of flexible hoses for T14-QT, T14, T26 (360mm)
  • SP644: Pair of valve body including cartridges for T14
  • SP889: Pop up basin waste of product T14, T14-QT, T26 (excluding the vertical pop up waste control rod)
  • SP149: T-Piece connecting hoses to spout -T14
  • SP45: T1, T2, T3 'Hot' and 'Cold' ceramic indice
  • SP48: T12, T13, T14, T15, T16, V25, V34, V36 'B' logo ceramic indice (D=22.2mm)
  • SP30: T14 1, 2 full turn cartridge
  • SP102: T14 pop up waste control rod

Specification

Product Type Traditional
Material T1: Tap handles - Brass
T14: Tap - Brass
T14-QT: Tap - Brass
T2: Tap handles - Brass
T3: Tap handles - Brass
T4: Tap handles - Brass
T4B: Regent tap base - Brass
Size T1: 267 x 267 x 65mm
T14: 2675 x 248 x 48mm
T14-QT: 2675 x 248 x 48mm
T2: 64 x 64 x 237mm
T3: 65 x 65 x 233mm
T4: 94 x 28 x 28mm
T4B: 545 x 545 x 273mm
Nett Weight T1: Tap handles - 0.18kg
T14: Tap - 2.3kg
T14-QT: Tap - 2.3kg
T2: Tap handles - 0.15kg
T3: Tap handles - 0.15kg
T4: Tap handles - 0.25kg
T4B: Regent tap base - 0.45kg
Gross Weight Including Packaging T1: Tap handles - 0.2kg
T14: Tap - 2.9kg
T14-QT: Tap - 2.9kg
T2: Tap handles - 0.2kg
T3: Tap handles - 0.2kg
T4: Tap handles - 0.3kg
T4B: Regent tap base - 0.75kg
Packed Dimension T1: 52 x 52 x 65 = 0.0002 m3
T14: 382 x 350 x 83 = 0.0111 m3
T14-QT: 382 x 350 x 83 = 0.0111 m3
T2: 52 x 52 x 65 = 0.0002 m3
T3: 70 x 65 x 65 = 0.0003 m3
T4: 105 x 70 x 35 = 0.0003 m3
T4B: 110 x 70 x 88 = 0.0007 m3
Colour T14: Tap - Chrome plated
T14-QT: Tap - Chrome plated
T2: Tap handles - Chrome plated
T4: Tap handles - Chrome plated
T4B: Regent tap base - Chrome plated
Barcode T14: 5055806006829
T2: 5055806006928
Packed Dimension T1: 52 x 52 x 65 = 0.0002 m3
T14: 382 x 350 x 83 = 0.0111 m3
T14-QT: 382 x 350 x 83 = 0.0111 m3
T2: 52 x 52 x 65 = 0.0002 m3
T3: 70 x 65 x 65 = 0.0003 m3
T4: 105 x 70 x 35 = 0.0003 m3
T4B: 110 x 70 x 88 = 0.0007 m3
Colour T14: Tap - Chrome plated
T14-QT: Tap - Chrome plated
T2: Tap handles - Chrome plated
T4: Tap handles - Chrome plated
T4B: Regent tap base - Chrome plated

Downloads

Click for Instructions T14 (English)

Click for Instructions T14 (French)
